PAC International RSIC-SI-CRC EZ

The RSIC-SI-CRC EZ is a ceiling-only spring isolation hanger for suspended gypsum ceilings. It mounts to wood or steel structure and supports a 1 1/2 in, 16-gauge cold-rolled steel carrier channel. Standard 7/8 in drywall furring channels are then tied or screwed across that carrier grid, creating a spring-isolated ceiling below the structure. PAC lists it for ceilings — for a resilient wall, specify the applicable tested wall design instead. It ships fully assembled and precalibrated, in color-coded load versions that must be selected for the tributary ceiling load at each hanger.

Front view of the mounting bracket, coil spring and lower carrier clip.
  • Suspends a CRC carrier grid: The EZ clip receives 1 1/2 in x 1/2 in x 1 1/2 in, 16-ga cold-rolled channel (SSMA 150U050-54). Drywall furring channel then crosses the CRC — it does not snap into this clip.
  • Spring deflection, not rubber: Total deflection is 1 in with double deflection of +/- 1/2 in, giving substantially more isolation travel than an ordinary rubber isolation clip.
  • Calibrated load versions: Yellow 5 lb, White 10 lb, Blue 20 lb, Green 30 lb (installation guide), Red 40 lb, Silver 80 lb. The rating is selected per hanger for its calculated tributary load.
  • Adjustable and preassembled: Ships fully assembled and precalibrated with up to 6 in of adjustment, for sloped, uneven or deeper cavities from about 1 in minimum (wood) to 9 in maximum.
  • Engineered ceilings: For engineered suspended gypsum ceilings in studios, theaters, gyms and multifamily or commercial rooms — not a simple residential retrofit clip.
$44.95
/ clip

Online orders up to 4,999 pieces. For anything larger, call (415) 864-4440 and we'll price the project with you.

Volume pricing

$44.95 per clip. Order 250+ clips and pay $44.55 per clip — an extra $0.40 off per clip for each additional 250 clips, down to a $42.24 per clip floor.

Discounts apply automatically in the cart and count boxes and cases toward the total.

Request Pro Install
Authorized PAC International DealerCeiling-only spring hangerLocal pickup: SF, San Leandro, LA
Product Specs

RSIC-SI-CRC EZ Specifications

Use on ceilings
Yes
Use on walls
No
Acoustical design load
Calibrated versions, 5 lb to 80 lb
Spring colors
Yellow 5 · White 10 · Blue 20 · Green 30 (guide) · Red 40 · Silver 80 lb
Total deflection
1 in (double deflection +/- 1/2 in)
Precalibration
Deflects about 1/2 in more once the gypsum is loaded
Max hanger spacing
48 in × 48 in o.c.
Cavity range
1 in min (wood) to 9 in max
Adjustment limit
Up to 6 in
Loaded height (drawing)
9 1/2 in overall, bracket through carrier channel
Upper bracket width (loaded drawing)
3 1/2 in
Mounting hole spacing (loaded drawing)
1 3/4 in on center
Spring housing height (loaded drawing)
4 3/8 in
Construction
New construction · preassembled and precalibrated
Interior use
40–100°F operating range
Companion Component

Channel grid

Carrier channel
1 1/2 in, 16-ga cold-rolled channel (CRC), nominal 1/2 in × 1 1/2 in × 1/2 in, SSMA 150U050-54
Carrier run spacing
Max 48 in o.c., matching the max 48 in × 48 in hanger grid
Drywall furring channel
7/8 in deep — 25-ga hemmed edge or 20-ga standard, meeting SSMA
Furring channel width
Bottom 2 9/16 in to 2 11/16 in · top 1 1/4 in
Furring channel spacing
24 in o.c. for one or two gypsum layers · 16 in o.c. for three, per the selected design and load
Furring channel splice
6 in overlap at midspan — two 7/16 in framing screws or double-wrapped 18-ga tie wire
Ceiling Hanger Estimator

RSIC-SI-CRC EZ Preliminary Estimate

Built for ceilings. Quantity is laid out off the actual support grid: carrier runs of 1-1/2 in, 16-ga CRC across the ceiling, with spring hangers along each run. Both directions max out at 48 in on center.

The final count comes off a reflected ceiling plan, not off area: plot the real carrier runs and hanger positions, keep both directions at or under 48 in, keep the first drywall support less than 8 in from the perimeter, stagger hangers where possible, and add hangers or blocking at boundaries, openings and nonstandard dimensions. PAC directs nonstandard room dimensions to a professional engineer.

Preliminary Material Estimate
Hangers (with waste)61
Field grid before waste55 hangers
Carrier runs5
Hangers per run11
1-1/2 in CRC carrier≈ 100 lin ft
Rough check — area ÷ 16 sq ft320 sq ft → 20
Spring selection check
Load used6.50 lb/sq ft
Tributary per hanger8.0 sq ft · 52.0 lb
Starting springSilver — 80 lb
Preliminary material estimate — not a final engineered layout. Hanger count and spring color are two separate checks: the grid sets the count, and every hanger's tributary load must sit within its calibrated rating without exceeding it. Confirm both against the selected design and the current PAC documents.
Product Comparison

How RSIC-SI-CRC EZ compares

ModelTypeSurfacesSupportsDeflectionLoad
RSIC-SI-CRC EZthisSpring isolation hangerCeilings only1 1/2 in, 16-ga CRC carrier grid, max 48 × 48 in o.c.1 in total (+/- 1/2 in double deflection)Calibrated 5 / 10 / 20 / 40 / 80 lb versions
RSIC-1Rubber isolation clipWalls and ceilings, per the applicable assembly7/8 in drywall furring channel directly — no CRC carrier gridRubber isolator, not a spring hangerApprox. 36 lb design load
Downloads

Data Sheets & Guides

PAC Clips — Data Sheets Library
Full datasheet archive
FAQ

RSIC-SI-CRC EZ — Common Questions

No. It is a ceiling spring hanger, so plan it from the ceiling grid rather than wall area. For a resilient wall, specify the tested wall design your project calls for.
